Basic Info.
Model NO.
CK1325
Spindle Number
Single-Spindle
Feed Mode
Mechanical
Controlling Mode
CNC
Certification
CE, ISO, FDA
Customized
Customized
Condition
New
Color
Customized
Transport Package
Plywood Packing
Specification
3200x2800x500mm
Trademark
CHANKE
Origin
Shandong China
HS Code
8465990000
Production Capacity
50 Set/Year
Product Description
- The worktable is vacuum working table, with very powerful absorbing power, can absorb materials of different sizes.
- Equipped with mach3 control system or NC studio or as your choice easy to operate.
- With high-performance drive motor to ensure that the machines working with high speed and accuracy.
- This one is a cheaper type of our facotry.
Technical Parameters:
| Description | Parameter |
| X,Y,Z Working Area | 1300x2500x200mm |
| Table Surface | T-slot Table with Vacuum pump working table |
| Spindle | 3kw Changsheng water cooling spindle |
| X, Y Structure | Taiwan PMI or ABBA 20#Linear guide |
| Z Structure | Taiwan TBI ball screw Transmission |
| Motor and driver | Stepper motor and leadshine driver |
| Spindle Speed | 0-24000RPM |
| Inverter | 3.7kw Fuling Inverter |
| Command Language | G Code |
| Control System | Mach3 control system or as your choice |
| Computer Interface | USB |
| X,Y Resolution | <0.01mm |
| Running Environment Temperature | 0 - 45 Centigrade |
| Relative Humidity | 30% - 75% |
| Lubrication system | Oil Lubrication System |
| Voltage | 380V,3phase,50HZ |
